Integrated Water-cooled Screw chiller
The Integrated Water-Cooled Screw Chiller is a chiller plant incorporating a water-cooled screw chiller, cooling equipment, cooling water pump, chilled water pump, water-side pipework, valves, water system accessories, a soundproofing device (optional), expansion tank, and control system within a modular frame. This innovative cooling system, which can replace conventional chiller plants, can be placed outdoors as a comprehensive unit.
Once connected to the water system and power supply on site, this unit is immediately operational for centralized cooling. It consolidates all the components of the cooling water system and most crucial elements of the chilled water system into a confined space, offering a highly integrated system that significantly saves initial investment, making it a cost-effective product.
Model: FLM-WX
Cooling capacity: 84-409kW
Refrigerant type: R410a, R513A, R1234ze
Standardized Assembly
Optimized Pipework Design
Enhanced Cooling Efficiency
Advanced Compressors
Technical Parameter
Standardized Assembly
Factory Standardization: The unit undergoes standardized assembly and testing within the factory, streamlining on-site construction and reducing the commissioning period for users.
Optimized Pipework Design
Integrated package design Design: Its assembly-style design ensures deep optimization of internal pipework, to minimize low water resistance and effectively lowering energy consumption in the water system.
Enhanced Cooling Efficiency
Built-in Cooling Components: With an integrated cooling water pump and cooling tower, the design significantly shortens the distance for cooling water distribution, slashing energy consumption by over 70% compared to traditional setups.
Advanced Compressors
High-Efficiency Compressors: The unit boasts high-efficiency dual-screw compressors, which are not only effective and stable but also safe and durable.
Efficient Heat Exchange
Full Liquid Evaporation Technology: This advanced technology ensures high heat exchange efficiency with minimal temperature differences.
Flexible Outdoor Installation
Outdoor Installation: The outdoor metal casing allows for installation in open-air environments, eliminating the need for a dedicated chiller plant room and saving on construction costs.
Unified Control System
Integrated Control System: It features an interconnected control of the compressor cooling system, cooling tower, and both the cooling and chilled water distribution systems, enabling easy operation with a single button for start-up and shutdown.
User-Friendly PLC Interface
Intelligent PLC Control: The system is managed by a PLC intelligent control system, complemented by an LCD true-color touchscreen for an intuitive and user-friendly interface.
